SB100、SB110 series solid breadboards
1. Used high quality aluminum alloy, high flatness, low weight, easy to move
2. M6 threaded holes array with distance 25mm in the surface for fixing device conveniently
3. Special surface treatment, good appearance and wearable
4. For special size and material can be customized
- description
- parameters
1. Thickness : 13mm(sb100)/19mm(SB110)
2. Flatness:0.08mm/m2
3. Distance between holes:25mm
4. Diameter of holes:M6
5. Material: high quality aluminum alloy
Model
Table size（mm）
Table thickness（mm）
SB101
300×300×13
13
SB102
300×600×13
13
SB103
600×600×13
13
SB104
450×600×13
13
SB111
300×300×19
19
SB112
300×600×19
19
SB113
600×600×19
19
