OCW-L series cemented zero order waveplate
1. Material: Crystal Quartz
2. Dimension Tolerance: +0.0/-0.2mm
3. Wavefront Distortion: λ/8@632.8nm
4. Retardation Tolerance: λ/300
5. Parallelism: <1 arc second
6. Surface Quality: 20/10
7. Clear Aperture: >90%
8. AR Coating: R<0.25%@central wavelength
9. Damage Threshold: >500mJ/cm2, 20ns, 20Hz @1064nm
- description
- parameters
|
Model |
Retardation |
Diameter(mm) |
Type |
Wavelength(nm) |
|
OCW-L-01 |
λ/2 |
10 |
Cemented |
488 - 1550 |
|
OCW-L-02 |
λ/2 |
12.7 |
Cemented |
488 - 1550 |
|
OCW-L-03 |
λ/2 |
15 |
Cemented |
488 - 1550 |
|
OCW-L-04 |
λ/2 |
20 |
Cemented |
488 - 1550 |
|
OCW-L-05 |
λ/2 |
25.4 |
Cemented |
488 - 1554 |
|
OCW-L-06 |
λ/2 |
30 |
Cemented |
488 - 1555 |
|
OCW-L-07 |
λ/2 |
38.1 |
Cemented |
488 - 1556 |
|
OCW-L-08 |
λ/2 |
50.8 |
Cemented |
488 - 1557 |
|
OCW-L-09 |
λ/2 |
10 |
Cemented |
488 - 1558 |
|
OCW-L-10 |
λ/2 |
12.7 |
Cemented |
488 - 1559 |
|
OCW-L-11 |
λ/2 |
15 |
Cemented |
488 - 1560 |
|
OCW-L-12 |
λ/2 |
20 |
Cemented |
488 - 1561 |
|
OCW-L-13 |
λ/2 |
25.4 |
Cemented |
488 - 1562 |
|
OCW-L-14 |
λ/2 |
30 |
Cemented |
488 - 1563 |
|
OCW-L-15 |
λ/2 |
38.1 |
Cemented |
488 - 1564 |
|
OCW-L-16 |
λ/2 |
50.8 |
Cemented |
488 - 1565 |
